The professional dry steam cleaner has been developed for highest industrial demand, can be used for cleaning in almost all industrial field and production. Machines such as paper-, plastic-, casting-, press-, punching-, milling and CNC-machines, production lines, robots… etc.
Mechanical and electrical installation as well as pneumatic and hydraulic components can be cleaned smoothly, and environmentally friendly, cost saving and effective.
Revisions and maintenance job on machines can be done on the spot without dismounting and interruption of the production process, this assure cost and time saving.
USER FRIENDLY
- Clear and easy
- Easy transport through tandem axle
- Air inflated tyres
- LED – system control with light diodes
MAINTENANCE FRIENDLY
-
Easy access to all components
ROBUST
- Frame out of metal
- Cover out of stainless steel
HIGH-PERFORMANCE
-
Very slow running 3 ceramic plunger pump Industrial motor 100% S1
EFFICIENT
- Compact construction
- Industrial accessories
- Low water consumption
- Saftety temperature up to 185 C°
- Addition of compressed air
model | DAS363 LXTS | DAS363 KXTS |
order-no. | DAS363 LXTS-013 | DAS363 KXTS-013 |
max. operating pressure [bar] | 16 bar | 16 bar |
max. flow rate by dry steam [l/min] | 0,9 | 0,9 |
max. flow rate by moisutre steam [l/min] | 2,0 | 2,0 |
max. flow rate by wet steam [l/min] | 2,7 | 2,7 |
power [kW] | 3,0 S1 Industrial motor | 3,0 S1 Industrial motor |
heating capacity [kW] | 63 oil heated | 63 oil heated |
voltage [V/Hz] | 1 ~ 230 V / 50 Hz | 3 ~ 400 V / 50 Hz |
max. water supply temperature [°C] | 30 | 30 |
high pressure pump | plunger pump with 3 ceramic plungers | plunger pump with 3 ceramic plungers |
rotation [rpm] | 1420 | 1420 |
compressed air requirement [l/min] | 500 | 500 |
measurement (lxwxh) [mm] | 1080x740x830 | 1080x740x830 |
weight [kg] | 145 | 145 |
apply recommendation |
products for business and industrial applications
recommended for semi proffesional use
